Production lines for parquet

Parquet production: Press lines that set standards

The natural material wood tends to change depending on temperature and weather conditions due to its ability to adapt to its environment. For this reason, different construction types and production methods have always been used to compensate for the natural behaviour of wood. As one of the pioneers in the development of fully integrated press lines, we are aware of these challenges in parquet production and our lines enable top quality for two- or three-layer parquet.

Robert Bürkle GmbH
Applications
Pressing
Production lines for parquet

Technology portfolio for parquet production lines

  • Feeding and stacking systems
  • Multi-level presses
  • Single-level presses
  • Lamella feeding
  • Middle layer production
  • Adhesive application machine
  • Brushing and cleaning machines
  • Handling systems and robotics
  • Conveyor technology

From individual machines to turnkey production lines for parquet flooring

From the top layer preparation and production to the centre layer lay-up and press line to the surface treatment with complete lacquering lines and subsequent packaging – BÜRKLE sets standards with the lines for the production of 2-layer or 3-layer parquet flooring with regard to the quality of the end product.





Laying and pressing line for 3-layer parquet flooring



Automatic import of raw planks for centre layer lamella production

Automatic import of raw planks for centre layer lamella production

Raw planks are fed into the line for the production of centre layer lamellas via an automatic infeed. The raw planks are automatically cut into scantlings and then automatically processed into centre layer lamellas.

Centre layer production

Centre layer production

The middle layer slats are positioned as a mat on the counter-draught via a shuttle. To save material, the slats can be placed on gap if required.

Laying area

Laying area

In the laying area, the top layer glued on one side is laid on the sandwich of backing and middle layer mat. A high degree of laying accuracy is absolutely essential here.

Chop saw and destacking

Chop saw and destacking

Following the pressing process, the parquet planks are cut into raw parquet planks using a cross-cut saw and then stacked fully automatically using a vacuum portal.
1

Automatic import of raw planks for centre layer lamella production

Raw planks are fed into the line for the production of centre layer lamellas via an automatic infeed. The raw planks are automatically cut into scantlings and then automatically processed into centre layer lamellas.

2

Centre layer production

The middle layer slats are positioned as a mat on the counter-draught via a shuttle. To save material, the slats can be placed on gap if required.

3

Laying area

In the laying area, the top layer glued on one side is laid on the sandwich of backing and middle layer mat. A high degree of laying accuracy is absolutely essential here.

4

Chop saw and destacking

Following the pressing process, the parquet planks are cut into raw parquet planks using a cross-cut saw and then stacked fully automatically using a vacuum portal.


Medium layer production (for 2-layer parquet)


Automatic import of raw planks for scantling production

Automatic import of raw planks for scantling production

The raw planks provided are automatically cut into scantlings at this position.

Chop saw

Chop saw

The produced scantlings are automatically cut into centre layer lamellas and divided into two different lanes. The cross-cut sections are distributed to the 2 lanes via a swivelling flap that only releases one lane at a time or forms a channel for the workpiece transport.

2-fold feeding of the centre layers Mat production

2-fold feeding of the centre layers Mat production

In order to increase the capacity of the mat production, two stations are fed with centre layer lamellae in parallel.

Centre layer mat production

Centre layer mat production

The slats provided can be placed on gap in the line so that the desired final dimensions are produced in a resource-saving way. Cords made of plastic or pure paper can be used as connecting elements.

Stacking

Stacking

The aligned and collected mats are stacked in layers on pallets. The stacking pattern is adapted in such a way that mat packs are stacked in a preselected number, staggered in relation to each other, and thus the feeding in the downstream press system is more effective.

1

Automatic import of raw planks for scantling production

The raw planks provided are automatically cut into scantlings at this position.

2

Chop saw

The produced scantlings are automatically cut into centre layer lamellas and divided into two different lanes. The cross-cut sections are distributed to the 2 lanes via a swivelling flap that only releases one lane at a time or forms a channel for the workpiece transport.

3

2-fold feeding of the centre layers Mat production

In order to increase the capacity of the mat production, two stations are fed with centre layer lamellae in parallel.

4

Centre layer mat production

The slats provided can be placed on gap in the line so that the desired final dimensions are produced in a resource-saving way. Cords made of plastic or pure paper can be used as connecting elements.

5

Stacking

The aligned and collected mats are stacked in layers on pallets. The stacking pattern is adapted in such a way that mat packs are stacked in a preselected number, staggered in relation to each other, and thus the feeding in the downstream press system is more effective.


01
02
Experience BÜRKLE production lines
Get first insights into our know-how
Contact now
00

Technologies for the production of parquet flooring

Please refer to our brochure for further information on our press systems for the production of parquet flooring.

Press lines for floors
pdf - 18 MB

Your advantages of our production lines for parquet

  • Lines from the general supplier for complete production systems for parquet flooring

  • Highly automated top layer production with high flexibility and material savings

  • Product-friendly hot presses for the targeted and uniform application of heat

  • Safety concept with CE certification which was planned and designed in detail

  • Data integration of ERP or CMS systems

  • Quick changeover to other lengths, widths and thicknesses of planks
